AP3012KTR-G1
Datasheet
1MB
Specifications
| Digi-Key Part Number | AP3012KTR-G1DITR-ND – Tape & Reel (TR) |
| AP3012KTR-G1DICT-ND – Cut Tape (CT) | |
| AP3012KTR-G1DIDKR-ND – Digi-Reel® | |
| Manufacturer | Diodes Incorporated |
| Manufacturer Product Number | AP3012KTR-G1 |
| Description | IC REG BOOST ADJ 500MA SOT23-5 |
| Manufacturer Standard Lead Time | 25 Weeks |
| Detailed Description | Boost Switching Regulator IC Positive Adjustable 1.25V 1 Output 500mA (Switch) SC-74A, SOT-753 |
| Category | Integrated Circuits (ICs) |
| PMIC – Voltage Regulators – DC DC Switching Regulators | |
| Mfr | Diodes Incorporated |
| Series | – |
| Package | Tape & Reel (TR) |
| Cut Tape (CT) | |
| Digi-Reel® | |
| Product Status | Active |
| Function | Step-Up |
| Output Configuration | Positive |
| Topology | Boost |
| Output Type | Adjustable |
| Number of Outputs | 1 |
| Voltage – Input (Min) | 2.6V |
| Voltage – Input (Max) | 16V |
| Voltage – Output (Min/Fixed) | 1.25V |
| Voltage – Output (Max) | 29V |
| Current – Output | 500mA (Switch) |
| Frequency – Switching | 1.5MHz |
| Synchronous Rectifier | No |
| Operating Temperature | -40°C ~ 85°C (TA) |
| Mounting Type | Surface Mount |
| Package / Case | SC-74A, SOT-753 |
| Supplier Device Package | SOT-23-5 |
| Base Product Number | AP3012 |
