640445-2
Datasheet
1MB
Specifications
| Digi-Key Part Number | A1971-ND |
| Manufacturer | TE Connectivity AMP Connectors |
| Manufacturer Product Number | 640445-2 |
| Description | CONN HEADER VERT 2POS 3.96MM |
| Manufacturer Standard Lead Time | 18 Weeks |
| Detailed Description | Connector Header Through Hole 2 position 0.156″ (3.96mm) |
| Category | Connectors, Interconnects |
| Rectangular Connectors – Headers, Male Pins | |
| Mfr | TE Connectivity AMP Connectors |
| Series | MTA-156 |
| Package | Bulk |
| Product Status | Active |
| Connector Type | Header |
| Contact Type | Male Pin |
| Pitch – Mating | 0.156″ (3.96mm) |
| Number of Positions | 2 |
| Number of Rows | 1 |
| Row Spacing – Mating | – |
| Number of Positions Loaded | All |
| Style | Board to Cable/Wire |
| Shrouding | Shrouded – 1 Wall |
| Mounting Type | Through Hole |
| Termination | Solder |
| Fastening Type | Friction Lock |
| Contact Length – Mating | 0.400″ (10.16mm) |
| Contact Length – Post | 0.125″ (3.18mm) |
| Overall Contact Length | 0.650″ (16.51mm) |
| Insulation Height | 0.425″ (10.80mm) |
| Contact Shape | Square |
| Contact Finish – Mating | Tin |
| Contact Finish Thickness – Mating | – |
| Contact Finish – Post | Tin |
| Contact Material | Copper Alloy |
| Insulation Material | Thermoplastic, Glass Filled |
| Features | – |
| Operating Temperature | -55°C ~ 105°C |
| Ingress Protection | – |
| Material Flammability Rating | UL94 V-0 |
| Insulation Color | Natural |
| Current Rating (Amps) | Varies by Wire Gauge |
| Voltage Rating | 600VAC |
| Mated Stacking Heights | – |
| Contact Finish Thickness – Post | – |
| Applications | General Purpose, Industrial |
| Base Product Number | 640445 |
